| Price: | Negotiable |
| Delivery Period: | 15-20 workdays |
| Payment Method: | LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram |
TOPTION handheld ultrasonic cell crusher add automatic or manual operation working mode ( foot switch is optional ).
Ultrasonic power could be continuously adjustable with 1% precision, transducer has small size and light weight, you could hold it in hand to do micro sample research, also could put it on fixed support.
Technical parameters of TOPTION UP Series Ultrasonic Cell Disruption:
| Model | UP-250 | UP-400 |
| Frequency
(KHz) |
20-30KHz Automatic tracking | 20-30KHz Automatic tracking |
| Power(W) | 2.5-250W adjustable | 5-400W adjustable |
| Horn (mm) | Φ3 or Φ5 | Φ6 |
| Optional Horn (mm) | Φ2,Φ3,Φ6 | Φ2,Φ3,Φ5,Φ8 |
| Crush Capacity
(ml) |
0.1-150 | 0.1-300 |
| Temperature alarm range | 0-100 ℃ | |
| Instrument protection function | Over-temperature | |
| Foot switch | Optional | |
| Display | 4.3 inch TFT | |
TOPTION TUN-R series ultrasonic cell crusher is used for asepsis crush, it could through centrifuge tube to break chromosome and crush cell ( suitable for biology dangerous products and harmful sample ), equipped with silencer hold-down device.
Compared with traditional probe ultrasonic cell crusher, traditional cell crusher’s probe need to contact with sample directly, need to use one same probe again and again, which is easy to cause sample cross pollution. And also as every time the depth of probe insert sample is not same, so each time ultrasonic energy distribution is not uniform,finally effect the repeatability and precision of research result.
For TUN-R series ultrasonic cell crusher, don’t need operate probe frequently, each sample is put in total closed individual test tube, ultrasonic energy distribution is uniform, high efficient experiment, reliable test result, excellent repeatability.
As all these advantages, TUN-R series ultrasonic cell crusher already become the standard instrument for ChIP ( chromatin co-immunoprecipitation ) and blood products, vaccine products, DNA shear research institution.
Technical parameters of this no-contact type ultrasonic homogenizing and blending:
| Model | TUN-R1200 | TUN-R2200 | TUN-R3200 |
| Frequency(KHz) | 19.5-20.5KHz Automatic tracking | ||
| Power(W) | 20-1200W adjustable | 100-2200W adjustable | 500-3200W adjustable |
| Horn (mm) | Φ20 | Φ60 | Φ70 |
| Standard crush capacity at a time (ml) | 1.5ml or 2ml *4 hole | 1.5ml or 2ml*16 hole | 1.5ml of 2ml*32 hole |
| Centrifugal pipe support optional (ml) | 0.2ml*8 hole or 0.5ml*6 hole or 5ml*3 hole | 0.5ml*18 hole or 5ml*18 hole or 15ml*15 hole or 50ml*5 hole | 0.5ml*48 hole or 5ml*18 hole or 15ml*15 hole or 50ml*5 hole or 250ml*1hole |
| Constant temp. Range ℃ | 0-100 degree centigrade ( Low temperature circulators & constant temperature circulators are optional) | ||
| Store data | 20 sets | ||
| Display | 4.3 inch TFT | ||
Large power no-contact type ultrasonic cell crusher:
TOPTION this type ultrasonic material emulsifying dispenser is most suitable to disperse nanometer materials (such as carbon nano tube, graphene, silicon dioxide).
Technical parameters of TOPTION this type 4.3 inch touch screen ultrasonic material disperse machine:
| Model | TUE-500 | TUE-1000 | TUE-1500 | TUE-3000 |
| Frequency (KHz) | 20-30KHz
Automatic tracking |
20-25KHz
Automatic tracking |
19.5-20.5KHz
Automatic tracking |
19.5-20.5KHz
Automatic tracking |
| Power (W) | 5-500W adjustable | 10-1000W adjustable | 20-1500W adjustable | 1000-3000W adjustable |
| Horn (mm) | Φ6 | Φ10 | Φ20 or 22 | Φ40(mm) lengthened type |
| Optional Horn (mm) | Φ2,Φ3,Φ8,Φ10 | Φ6,Φ8,Φ10,Φ12,Φ15 | Φ10,Φ15,Φ25 | Φ20,Φ35,Φ40 lengthened type, Φ50(mm) |
| Crush capacity (ml) | 0.2-400 | 10-600 | 50-1500 | 500-5000 |
| Instrument protection function | Over-temperature protection | Over-temperature protection | Over-temperature, protection | Over-temperature, protection |
| Display | 4.3 inch TFT | 4.3 inch TFT | 4.3 inch TFT | 4.3 inch TFT |
|
|
