Vacuum pumps are designed on the basis of the principle of generating negative pressure by using the jet flow and using the recycled water as the working fluid, which can provide the vacuum conditions for chemical experiments, and recirculated cooling water for the reaction equipment.
| Vacuum degree | 0.098MPa | Single-mouth suction rate | 10L/min |
| Pump displacement | 90L/ min | Water tank capacity | 15L |
| Motor power | 180W | Operating voltage | 110V～220V±10%, 50HZ |
| Noise | <50dB | Dimensions | 385*285*420mm |
| Weight | 15kg | Under the standard atmospheric pressure, the recycled water temperature is 0-25 ℃ | |
Advantages of SHB-III water circulation multifunction vacuum pump:
1. Obvious water-saving effect. The water added into the water tank can be recycled for the water cycle operation, which overcomes the shortcoming of wasting a lot of water to generate a vacuum environment by directly discharging the tap water.
2. Multi-functional and integrated roles. This product, besides providing the vacuum conditions, can also equally perform the external cycle operation and provide recirculated cooling water for the reaction equipment.
3. Novelty appearance and easy usage. The pump head of this product can be directly immersed in water.The complete machine is characterized by low height, small size, light weight and convenient movement,can be put on the workbench, easy for operation and observation.
4. Individual or simultaneous air pumping operation for the installation of two suction mouths.
5. Corrosion-resistant and pollution-free. The pump of this product is made of stainless steel, not subject to the influence of acid-base corrosion materials, and equally not going to produce any greasy dirt and impurities and so on that will pollute the laboratory.
6. Stable and reliable operation and low noise.
7. Main components are all made of stainless steel materials, with the water tank made of plastic material newly developed, which can prevent the damage from the dissolution and corrosion of organic solvents .
1. Obvious water-saving effect. The water added into the water tank can be recycled for the water cycle operation.
2. Multi-functional and integrated roles. Besides providing the vacuum conditions, can also equally perform the external cycle operation and provide recirculated cooling water for the reaction equipment.
3. Individual or simultaneous air pumping operation for the installation of five suction mouths.
4. The suction pipeline is equipped with check valves to prevent the recycled water from backing into the equipment of being vacuumized in case of accidental shut down in the process of vacuum operation.
5. Corrosion-resistant and pollution-free.
| Vacuum degree | 0.098MPa | Single-mouth suction rate | 10L/min |
| Pump displacement | 80L/ min | Water tank capacity | 57L |
| Motor power | 370W | Operating voltage | 110V～220V±10%, 50HZ |
| Noise | <50dB | Dimensions | 450*350*820mm |
| Weight | 40kg | Under the standard atmospheric pressure, the recycled water temperature is 0-25 ℃ | |
Rotary vane vacuum pump is usually used as vacuum system of glass reactor, rotary evaporator, freeze dryer, laboratory short path distillation kit,etc.
|
Model |
2XZ-2 |
Pumping speed(L/s) |
2 |
|
Ultimate pressure (Pa) |
0.06 |
speed(r/min) |
1400 |
|
Motor power(Kw) |
0.37 |
voltage(v) |
220/380 |
|
Noise(dBA) |
68 |
Oil volume (L) |
1 |
Vacuum pump for chemical glass reactor, 2L short path distillation kit, rotary evaporator, vacuum freeze dryer etc, contact info@toption-china.com CE certification reliable quality guarantee.
TOPTION Diaphragm Vacuum Pump has the features of continuous oil free pumping , low noise level , higher efficiency , long lifetime.
This series diaphragm pump is used with the precision chromatography instrument, solvent filter, stainless steel filter,etc, specially designed for laboratory, reliable and easy to use.
Laboratory diaphragm pump is mainly used in medicinal products analysis , industry of fine chemicals , biochemical pharmacy , food examination , The criminal investigation technology, etc.
Non oil vacuum pump (positive pressure optional) is also named as oil free vacuum pump, oil free diaphragm vacuum pump, which is a kind of oil free lubrication compressor, compressed air purity, large displacement.
1.Pressure digital display, easy operation, stable performance, high precision measurement, quickly response speed.
2. Small volume, light weight, portable structure.
3. Oil-free piston pump, imported movement seals, low noise, long service life.
4. Continuous negative pressure regulation.
5. Electromagnetic motor, piston straight reciprocating movement produce compressed gas, large gas displacement.
6. Oil-free lubrication design, compressed air is more pure.
7. Cylinder and piston use SF-1 new wear-resisting material, long service life.
8. Pump shell is made of high quality ZL102 aluminum alloy material, cooperate with streamline design, heat dissipation effect is better.
9. Surface phosphating treatment, electrostatic spraying, colour and lustre is uniform, stronger adhesion.
10. Strong corrosion resistance, high-end laboratory pump.
11. Teflon material, can be used for pumping strong acid & alkali gas.
12. Single pump head, vacuum degree can reach 8 mbar, positive & negative pressure double use (positive pressure optional).
13. Support 24 hours long time running.
Note: Strickly forbidden charging oil and organic solvent.
Related stainless steel vacuum filter and glass solvent filter
|
|
